09.F5.CBB-YM00 KEB COMBIVERT drive

KEB COMBIVERT drive for controlling a connected three-phase motor in a machine system.

System function

Rebuilt from individual evidence

System position

Unknown: evidence and limits require installation-specific verification.

The KEB COMBIVERT F5 drive controls a connected three-phase motor in the machine drive system.

Inferred system position: the drive sits between the three-phase supply and the motor, under the machine control path.

Unknown: compatibility with a specific machine, firmware, motor and parameter set.

Exact reference: 09.F5.CBB-YM00
Category: Drives / VFD
Evidence checked: 2026-09-11

System role

This section explains what the product does and where it acts in the surrounding system.

Function: The KEB COMBIVERT F5 drive controls a connected three-phase motor in the machine drive system.
System position: Inferred system position: the drive sits between the three-phase supply and the motor, under the machine control path.
Upstream / inputs: The three-phase electrical supply and machine control path provide the drive's upstream inputs.
Downstream / outputs: The connected motor receives the drive's controlled electrical output.
Limitations: Unknown: compatibility with a specific machine, firmware, motor and parameter set.

Evidence ledger

Facts, inferences, and unknowns are kept separate.

Facts

The captured source identifies 09.F5.CBB-YM00 as a KEB COMBIVERT F5 drive or inverter.
Confidence: medium
- www.radwell.com — retrieved 2026-09-11; medium confidence
The KEB COMBIVERT F5 drive controls a connected three-phase motor in the machine drive system.
Confidence: high
- www.radwell.com — retrieved 2026-09-11; medium confidence
- www.kebamerica.com — retrieved 2026-09-11; high confidence

Inferences

Inferred system position: the drive sits between the three-phase supply and the motor, under the machine control path.
Confidence: medium
Rationale: The exact listing establishes the reference as a drive or inverter, while the family documentation establishes motor control; the supply-to-motor position is therefore stated as an inference.
- www.radwell.com — retrieved 2026-09-11; medium confidence
- www.kebamerica.com — retrieved 2026-09-11; high confidence

Unknowns

Unknown: compatibility with a specific machine, firmware, motor and parameter set.
Confidence: low
Missing evidence: No machine-specific wiring, firmware, motor or parameter record was captured in this lookup.

System position diagram

A three-phase supply and machine control path feed the KEB drive, which sends controlled output to a connected motor. — The KEB drive is positioned between the machine supply and the connected motor.

View Mermaid source

flowchart LR; Supply[Three-phase supply] --> Drive[KEB drive]; Control[Machine control] --> Drive; Drive --> Motor[Connected motor]

View diagram labels

Nodes: Three-phase supply; Machine control; KEB drive; Connected motor
Edges: Electrical input; Control path; Controlled motor output

Next action

The captured evidence supports publishing this exact KEB drive reference as a motor-control component.

Unknown: confirm the machine, motor, firmware and parameter configuration before replacement or commissioning.
