Danfoss FCP322 motor-mounted drive - 177H0005

A sourced Danfoss motor-mounted drive record with an inferred motor-side position and explicit installation unknowns.

Documented identity

Rebuilt from individual evidence

System position

Unknown: evidence limits

The source identifies this exact reference as a Danfoss FCP322 motor-mounted drive.

Inferred system position: it is mounted at the motor end of the machine power path.

Unknown: installation compatibility, firmware, wiring, condition, and motor parameters.

Exact reference: 177H0005
Category: Drives / VFD
Evidence checked: 2026-09-11

System role

This section explains what the product does and where it acts in the surrounding system.

Function: The Danfoss motor-mounted drive controls the connected motor from the motor-side installation point.
System position: Inferred system position: the drive is mounted at the motor end of the machine power path.
Upstream / inputs: The upstream supply and machine control commands enter the motor-mounted drive.
Downstream / outputs: The drive sends controlled electrical power to its connected motor.
Limitations: Unknown: installed motor, parameter set, firmware, wiring, condition, and compatibility.

Evidence ledger

Facts, inferences, and unknowns are kept separate.

Facts

The exact-reference listing identifies 177H0005 as a Danfoss FCP322 motor-mounted drive.
Confidence: high
- afi-systems.com — retrieved 2026-09-11; high confidence

Inferences

Inferred system position: the drive is mounted at the motor end of the machine power path.
Confidence: high
Rationale: The exact listing explicitly describes a motor-mounted Danfoss drive, so the motor-side position is an inference from that documented mounting description.
- afi-systems.com — retrieved 2026-09-11; high confidence

Unknowns

Unknown: installed motor, parameter set, firmware, wiring, condition, and compatibility.
Confidence: low
Missing evidence: No installation-specific record was found.

System position diagram

Supply feeds the Danfoss motor-mounted drive, which feeds the machine motor. — Inferred motor-side power path through the Danfoss drive.

View Mermaid source

flowchart LR; supply[Supply] --> drive[Motor mounted drive]; drive --> motor[Motor]

View diagram labels

Nodes: Incoming supply; Danfoss motor-mounted drive; Machine motor
Edges: Drive regulates motor power

Next action

Evidence supports a conservative motor-mounted drive record; verify installation details before use.

Unknown: verify wiring, firmware, condition, motor data, and compatibility before installation.
