1FT6105-8AF71-3EA1 industrial motor

1FT6105-8AF71-3EA1 is documented as an exact industrial component with a concrete system role; installation-specific limits remain explicit.

System function

Rebuilt from individual evidence

Evidence-backed specifications

Siemens identifies 1FT6105-8AF71-3EA1 as a SIMOTICS S synchronous servomotor.

The Siemens data sheet specifies 50 Nm, 3000 rpm, natural cooling, IM B5, absolute EnDat 2048 S/R, axial non-drive-end connector outlet, feather-key shaft, no holding brake, and IP65 sealing.

This system placement is an inference from the captured exact-reference evidence.

Exact reference: 1FT6105-8AF71-3EA1
Category: Motors / Servo
Evidence checked: 2026-09-11

System role

This section explains what the product does and where it acts in the surrounding system.

Function: Converts controlled servo-drive electrical output into rotary torque for a machine axis.
System position: Sits between a compatible servo drive and the driven machine axis.
Upstream / inputs: Receives controlled three-phase electrical power and absolute encoder wiring from the servo drive.
Downstream / outputs: Transmits rotary torque to the machine mechanism under drive control.
Limitations: Unknown: installed drive compatibility, machine load, wiring, commissioning state, and current commercial availability.

Evidence ledger

Facts, inferences, and unknowns are kept separate.

Facts

Siemens identifies 1FT6105-8AF71-3EA1 as a SIMOTICS S synchronous servomotor.
Confidence: high
- my.goagilix.com — retrieved 2026-09-11; high confidence
The Siemens data sheet specifies 50 Nm, 3000 rpm, natural cooling, IM B5, absolute EnDat 2048 S/R, axial non-drive-end connector outlet, feather-key shaft, no holding brake, and IP65 sealing.
Confidence: high
- my.goagilix.com — retrieved 2026-09-11; high confidence

Inferences

Converts controlled servo-drive electrical output into rotary torque for a machine axis.
Confidence: medium
Rationale: The exact-reference sources identify the component and its documented technical characteristics; this concrete system function is an explicit system-level inference.
- my.goagilix.com — retrieved 2026-09-11; high confidence
Sits between a compatible servo drive and the driven machine axis.
Confidence: medium
Rationale: The exact-reference identity and technical data support this placement in a controlled industrial signal or power chain; the placement is labeled as an inference.
- my.goagilix.com — retrieved 2026-09-11; high confidence

Unknowns

Unknown: Unknown: installed drive compatibility, machine load, wiring, commissioning state, and current commercial availability.
Confidence: low
Missing evidence: The individual exact-reference research did not capture a complete installed-system configuration or current unit record.

System position diagram

A controlled upstream source feeds 1FT6105-8AF71-3EA1, which provides the documented output to a downstream machine load or input. — The 1FT6105-8AF71-3EA1 system position is shown from the documented role; the chain is an explicit inference.

View Mermaid source

flowchart LR\n  upstream["Upstream supply or controller"] --> item["1FT6105-8AF71-3EA1"]\n  item --> downstream["Downstream machine load or input"]

View diagram labels

Nodes: Upstream supply or controller; 1FT6105-8AF71-3EA1; Downstream machine load or input
Edges: Controlled input; System output

Next action

The captured evidence supports a concrete system role for 1FT6105-8AF71-3EA1; the chain position is explicitly inferred.

Verify the complete article number, receiving drive or supply, mechanical interface, and installation limits before replacement or commissioning.
