1LE1002-0CA22-2AA4 industrial motor

1LE1002-0CA22-2AA4 is documented as an exact industrial component with a concrete system role; installation-specific limits remain explicit.

System function

Rebuilt from individual evidence

Evidence-backed specifications

The Siemens SA Argentina catalog identifies 1LE1002-0CA22-2AA4 as a SIMOTICS 1LE1 motor.

The catalog row specifies 0.37 kW, IEC 71M, IE1, 2755 rpm, and 1.3 Nm; the catalog section gives 230 V delta / 400 V star at 50 Hz for the listed motor family.

This system placement is an inference from the captured exact-reference evidence.

Exact reference: 1LE1002-0CA22-2AA4
Category: Motors / Servo
Evidence checked: 2026-09-11

System role

This section explains what the product does and where it acts in the surrounding system.

Function: Converts three-phase electrical power into rotary torque for a driven machine.
System position: Sits between the three-phase motor supply and the driven machine load.
Upstream / inputs: Receives the cataloged three-phase supply through the motor terminals.
Downstream / outputs: Transmits rotary torque to the connected mechanical load.
Limitations: Unknown: installation-specific voltage selection, mounting details, protection coordination, machine load, and current commercial availability.

Evidence ledger

Facts, inferences, and unknowns are kept separate.

Facts

The Siemens SA Argentina catalog identifies 1LE1002-0CA22-2AA4 as a SIMOTICS 1LE1 motor.
Confidence: high
- motores-electricos.com.ar — retrieved 2026-09-11; high confidence
The catalog row specifies 0.37 kW, IEC 71M, IE1, 2755 rpm, and 1.3 Nm; the catalog section gives 230 V delta / 400 V star at 50 Hz for the listed motor family.
Confidence: high
- motores-electricos.com.ar — retrieved 2026-09-11; high confidence

Inferences

Converts three-phase electrical power into rotary torque for a driven machine.
Confidence: medium
Rationale: The exact-reference sources identify the component and its documented technical characteristics; this concrete system function is an explicit system-level inference.
- motores-electricos.com.ar — retrieved 2026-09-11; high confidence
Sits between the three-phase motor supply and the driven machine load.
Confidence: medium
Rationale: The exact-reference identity and technical data support this placement in a controlled industrial signal or power chain; the placement is labeled as an inference.
- motores-electricos.com.ar — retrieved 2026-09-11; high confidence

Unknowns

Unknown: Unknown: installation-specific voltage selection, mounting details, protection coordination, machine load, and current commercial availability.
Confidence: low
Missing evidence: The individual exact-reference research did not capture a complete installed-system configuration or current unit record.

System position diagram

A controlled upstream source feeds 1LE1002-0CA22-2AA4, which provides the documented output to a downstream machine load or input. — The 1LE1002-0CA22-2AA4 system position is shown from the documented role; the chain is an explicit inference.

View Mermaid source

flowchart LR\n  upstream["Upstream supply or controller"] --> item["1LE1002-0CA22-2AA4"]\n  item --> downstream["Downstream machine load or input"]

View diagram labels

Nodes: Upstream supply or controller; 1LE1002-0CA22-2AA4; Downstream machine load or input
Edges: Controlled input; System output

Next action

The captured evidence supports a concrete system role for 1LE1002-0CA22-2AA4; the chain position is explicitly inferred.

Verify the complete article number, receiving drive or supply, mechanical interface, and installation limits before replacement or commissioning.
