1PH7167-2QF23-0DJ0 industrial motor

1PH7167-2QF23-0DJ0 is documented as an exact industrial component with a concrete system role; installation-specific limits remain explicit.

System function

Rebuilt from individual evidence

Evidence-backed specifications

The Siemens data sheet identifies 1PH7167-2QF23-0DJ0 as a SIMOTICS M compact asynchronous motor.

The Siemens data sheet specifies 37 kW, 1500 rpm, 235.5 Nm, 400 V three-phase 50 Hz, fan cooling, a relative 1 VSS 2048 P/U DRIVE-CLiQ encoder, IM B35, IP55 motor protection, and no brake.

This system placement is an inference from the captured exact-reference evidence.

Exact reference: 1PH7167-2QF23-0DJ0
Category: Motors / Servo
Evidence checked: 2026-09-11

System role

This section explains what the product does and where it acts in the surrounding system.

Function: Converts controlled three-phase drive output into rotary torque for a machine spindle or axis.
System position: Sits between the motor drive and the driven machine spindle or axis.
Upstream / inputs: Receives controlled 400 V three-phase power and DRIVE-CLiQ encoder feedback from the drive.
Downstream / outputs: Transmits rotary torque to the connected spindle or mechanical load.
Limitations: Unknown: installed drive parameters, cooling installation, machine load, wiring, and replacement suitability.

Evidence ledger

Facts, inferences, and unknowns are kept separate.

Facts

The Siemens data sheet identifies 1PH7167-2QF23-0DJ0 as a SIMOTICS M compact asynchronous motor.
Confidence: high
- cdn.plc-trade.com — retrieved 2026-09-11; high confidence
The Siemens data sheet specifies 37 kW, 1500 rpm, 235.5 Nm, 400 V three-phase 50 Hz, fan cooling, a relative 1 VSS 2048 P/U DRIVE-CLiQ encoder, IM B35, IP55 motor protection, and no brake.
Confidence: high
- cdn.plc-trade.com — retrieved 2026-09-11; high confidence

Inferences

Converts controlled three-phase drive output into rotary torque for a machine spindle or axis.
Confidence: medium
Rationale: The exact-reference sources identify the component and its documented technical characteristics; this concrete system function is an explicit system-level inference.
- cdn.plc-trade.com — retrieved 2026-09-11; high confidence
Sits between the motor drive and the driven machine spindle or axis.
Confidence: medium
Rationale: The exact-reference identity and technical data support this placement in a controlled industrial signal or power chain; the placement is labeled as an inference.
- cdn.plc-trade.com — retrieved 2026-09-11; high confidence

Unknowns

Unknown: Unknown: installed drive parameters, cooling installation, machine load, wiring, and replacement suitability.
Confidence: low
Missing evidence: The individual exact-reference research did not capture a complete installed-system configuration or current unit record.

System position diagram

A controlled upstream source feeds 1PH7167-2QF23-0DJ0, which provides the documented output to a downstream machine load or input. — The 1PH7167-2QF23-0DJ0 system position is shown from the documented role; the chain is an explicit inference.

View Mermaid source

flowchart LR\n  upstream["Upstream supply or controller"] --> item["1PH7167-2QF23-0DJ0"]\n  item --> downstream["Downstream machine load or input"]

View diagram labels

Nodes: Upstream supply or controller; 1PH7167-2QF23-0DJ0; Downstream machine load or input
Edges: Controlled input; System output

Next action

The captured evidence supports a concrete system role for 1PH7167-2QF23-0DJ0; the chain position is explicitly inferred.

Verify the complete article number, receiving drive or supply, mechanical interface, and installation limits before replacement or commissioning.
