440R-H23176 Allen-Bradley MSR210 safety relay base module

Clean-room evidence identifies 440R-H23176 as Allen-Bradley MSR210 safety relay base module. Rockwell documentation lists 440R-H23176 as an MSR210 base module used with interlocks, emergency stops, and safety mats.

Documented identity and function

Rebuilt from individual evidence

System position

Rockwell documentation lists 440R-H23176 as an MSR210 base module used with interlocks, emergency stops, and safety mats.

The exact module wiring reference documents dual input channels S11/S12 and S21/S22, feedback terminals channel 1 and channel 2, and reset terminal S34.

The system path is inferred as dual-channel emergency-stop or guard inputs and the reset circuit, then 440R-H23176, then the machine contactor or safety output circuit.

Unknown: installation compatibility, configuration, and unit condition are not established by the captured sources.

Exact reference: 440R-H23176
Category: PLC / CPU
Evidence checked: 2026-09-11

System role

This section explains what the product does and where it acts in the surrounding system.

Function: The MSR210 safety relay monitors dual-channel safety inputs and switches safety outputs for a machine control circuit.
System position: It intervenes between dual-channel emergency-stop or guard inputs and the reset circuit and the machine contactor or safety output circuit in the documented system path.
Upstream / inputs: Inputs or upstream: dual-channel emergency-stop or guard inputs and the reset circuit.
Downstream / outputs: Outputs or downstream: the machine contactor or safety output circuit.
Limitations: Unknown: installation compatibility, configuration, and unit condition are not established by the captured sources.
