Siemens 6ED1052-1CC08-0BA1 LOGO! 24 CE logic module with display

Siemens 6ED1052-1CC08-0BA1 is documented for the stated industrial system role: Executes the programmed LOGO! logic, processes field inputs, switches transistor outputs, and exposes the documented Ethernet services.

System function

Rebuilt from individual evidence

System position

Siemens identifies 6ED1052-1CC08-0BA1 as a LOGO! 24CE logic module with display, 24 V DC/transistor I/O, 8 inputs with four analog-capable inputs, and 4 outputs.

Siemens lists 400-block memory, Ethernet, an integrated web server, data logging, user-defined web pages, and standard microSD support for the exact module.

Executes the programmed LOGO! logic, processes field inputs, switches transistor outputs, and exposes the documented Ethernet services.

The system position is an explicit inference from the exact-reference evidence.

Unknown: firmware level, loaded program, network configuration, output load, and installation-specific compatibility.

Exact reference
6ED1052-1CC08-0BA1
Category
PLC / CPU
Evidence checked
2026-09-12

System role

This section explains what the product does and where it acts in the surrounding system.

Function
Executes the programmed LOGO! logic, processes field inputs, switches transistor outputs, and exposes the documented Ethernet services.
System position
Sits between field I/O and machine loads as the LOGO! base controller, with Ethernet linking it to supervisory tools.
Upstream / inputs
Receives 24 V DC power and up to eight documented digital input signals, four of which can be used as analog inputs.
Downstream / outputs
Switches four transistor outputs and publishes the controller data through its documented Ethernet functions.
Limitations
Unknown: firmware level, loaded program, network configuration, output load, and installation-specific compatibility.

Evidence ledger

Facts, inferences, and unknowns are kept separate.

Facts

  • Siemens identifies 6ED1052-1CC08-0BA1 as a LOGO! 24CE logic module with display, 24 V DC/transistor I/O, 8 inputs with four analog-capable inputs, and 4 outputs.

    Confidence: high

  • Siemens lists 400-block memory, Ethernet, an integrated web server, data logging, user-defined web pages, and standard microSD support for the exact module.

    Confidence: high

Inferences

  • Inferred system position: Sits between field I/O and machine loads as the LOGO! base controller, with Ethernet linking it to supervisory tools.

    Confidence: high

    Rationale: The exact-reference sources establish the product identity and documented interfaces; their relationship to the stated upstream and downstream elements is marked as an inference.

Unknowns

  • Unknown: firmware level, loaded program, network configuration, output load, and installation-specific compatibility.

    Confidence: low

    Missing evidence: The individual lookup does not establish the installation, configured software, physical condition, or current commercial record.

System position diagram

A system diagram places Siemens 6ED1052-1CC08-0BA1 LOGO! 24 CE logic module with display between Field sensors, switches, and 24 V DC control supply and Transistor-controlled machine loads and Ethernet-connected supervisory tools; the placement is marked as an inference.

Reading limit: system position only, not a wiring or safety drawing.

The component placement between the documented upstream and downstream elements is an explicit inference.

Enlarged system diagram

A system diagram places Siemens 6ED1052-1CC08-0BA1 LOGO! 24 CE logic module with display between Field sensors, switches, and 24 V DC control supply and Transistor-controlled machine loads and Ethernet-connected supervisory tools; the placement is marked as an inference.

The component placement between the documented upstream and downstream elements is an explicit inference.

View Mermaid source
flowchart LR; Upstream-->Component; Component-->Downstream
View diagram labels
Nodes
Field sensors, switches, and 24 V DC control supply; Siemens 6ED1052-1CC08-0BA1 LOGO! 24 CE logic module with display; Transistor-controlled machine loads and Ethernet-connected supervisory tools
Edges
Input and control data; Processed output

Next action

Siemens catalog evidence supports the exact identity, control function, interfaces, and system position.

Confirm the target controller, wiring, configuration, and installation constraints before deployment or replacement.
