Siemens 6ES7223-1PL22-0XA0 documented industrial automation module

6ES7223-1PL22-0XA0 is documented as a Siemens controller or signal module with the cited function and system position.

System function

Rebuilt from individual evidence

Evidence and limits

The cited Siemens technical data sheet identifies 6ES7223-1PL22-0XA0 as an S7-200 EM 223 digital I/O module for S7-22X CPUs with 16 inputs and 16 relay outputs.

SIMATIC S7-200 EM 223 provides 16 24 V DC sink/source inputs and 16 relay outputs rated at 2 A per channel for S7-22X CPUs.

The system position is an inference from the exact-reference evidence; installation-specific compatibility remains unknown.

Exact reference: 6ES7223-1PL22-0XA0
Category: PLC / CPU
Evidence checked: 2026-09-12

System role

This section explains what the product does and where it acts in the surrounding system.

Function: Receives digital field signals and switches digital loads in the documented SIMATIC controller system.
System position: Sits in the controller signal path between field devices or power connections and the CPU processing program.
Upstream / inputs: Receives field signals or the controller backplane connection described by the cited evidence.
Downstream / outputs: Sends the documented switching states to connected digital loads.
Limitations: Unknown: Installation-specific compatibility, wiring, firmware, project configuration, condition and commercial status were not captured.
