ABB ACS580-01-046A-4 22 kW wall-mounted variable speed drive

ABB ACS580-01-046A-4 wall-mounted variable speed drive: 22 kW, 45 A, 400 V, for three-phase machine speed and torque control.

System function and position

Rebuilt from individual evidence

Evidence-backed applications

Unknown: limits requiring verification

The ACS580-01-046A-4 is documented as a low-voltage AC general-purpose wall-mounted drive with 22 kW nominal power, 45 A nominal output current, and a 400 V rating.

Its documented system role is to control the speed and torque of a three-phase electric machine; ABB lists compressors, conveyors, mixers, pumps, centrifuges, and fans as ACS580-01 applications.

ABB's family documentation lists integrated Safe Torque Off, Modbus RTU, USB PC connection, EMC filtering, and option slots; confirm the installed configuration before relying on an option or interface.

Unknown: the installed electric machine, wiring, parameter set, fieldbus options, enclosure option, and site conditions for this specific unit.

Exact reference: ACS580-01-046A-4
Category: Drives / VFD
Evidence checked: 2026-09-11

System role

This section explains what the product does and where it acts in the surrounding system.

Function: Controls the speed and torque of a three-phase electric machine in a general-purpose drive application.
System position: Sits between the three-phase AC supply and the electric machine that drives a process load.
Upstream / inputs: The upstream side is the documented three-phase 380-480 V supply and the drive control interface.
Downstream / outputs: Provides controlled machine operation for loads such as pumps, fans, conveyors, compressors, mixers, and centrifuges.
Limitations: Unknown: site-specific electric-machine compatibility, options, wiring, parameters, and installation conditions require verification.

Evidence ledger

Facts, inferences, and unknowns are kept separate.

Facts

ABB identifies ACS580-01-046A-4 as a low-voltage AC general-purpose wall-mounted drive with IEC nominal power of 22 kW, nominal output current of 45 A, and a 400 V rating.
Confidence: high
- www.abb.com — retrieved 2026-09-11; high confidence
- library.e.abb.com — retrieved 2026-09-11; high confidence
ABB's environmental profile states that the ACS580-01-046A-4 variable speed drive controls the speed and torque of three-phase electric motors.
Confidence: high
- library.e.abb.com — retrieved 2026-09-11; high confidence
ABB lists compressors, conveyors, mixers, pumps, centrifuges, and fans among ACS580-01 applications.
Confidence: high
- library.e.abb.com — retrieved 2026-09-11; high confidence
- library.e.abb.com — retrieved 2026-09-11; high confidence
ABB's ACS580 family flyer lists integrated Safe Torque Off, a removable Modbus RTU terminal, USB PC connection, an integrated EMC filter, and two option slots.
Confidence: high
- library.e.abb.com — retrieved 2026-09-11; high confidence
ABB documents a three-phase 380-480 V input range for ACS580-01 drives and identifies IP21 as the standard enclosure protection; the exact profile lists ACS580-01-046A-4 at 400 V and IP21.
Confidence: high
- library.e.abb.com — retrieved 2026-09-11; high confidence
- library.e.abb.com — retrieved 2026-09-11; high confidence

Inferences

In a motor-driven machine, the drive sits between the three-phase AC supply and the motor that drives the process load.
Confidence: medium
Rationale: ABB documents this exact reference as a wall-mounted variable speed drive, says it controls three-phase motor speed and torque, and names motor-driven loads; the exact site wiring topology still requires verification.
- www.abb.com — retrieved 2026-09-11; high confidence
- library.e.abb.com — retrieved 2026-09-11; high confidence
- library.e.abb.com — retrieved 2026-09-11; high confidence

Unknowns

Unknown: the installed motor, wiring, parameter set, fieldbus options, enclosure option, and site conditions for this specific unit.
Confidence: low
Missing evidence: No site inspection, motor nameplate, parameter backup, cabinet record, or option-card record was supplied.

System position diagram

Diagram showing a three-phase supply feeding the ABB drive, the drive controlling an electric machine, and the machine driving a listed process load. — The drive is positioned between the three-phase supply and a machine-driven process load.

View Mermaid source

flowchart LR
  AC["Three-phase AC supply"] -->|"380-480 V input"| Drive["ACS580-01-046A-4 drive"]
  Drive -->|"Controlled speed and torque"| Machine["Three-phase electric machine"]
  Machine -->|"Machine-driven process"| Load["Pump, fan, conveyor, compressor, mixer, or centrifuge"]

View diagram labels

Nodes: Three-phase AC supply; ACS580-01-046A-4 drive; Three-phase electric machine; Listed machine-driven process load
Edges: 380-480 V input; Controlled speed and torque; Machine-driven process

Next action

The captured manufacturer evidence supports the exact identity, rating, and concrete drive function; verify the installation context before making a compatibility decision.

Verify the machine nameplate, wiring, installed options, enclosure, and parameter backup against ABB documentation before repair or replacement.
