ABB ACS850-04 drive module ACS850-04-094A-5

ACS850-04-094A-5 is documented as a abb acs850-04 drive module; verify installation fit before use.

Documented system role and rating

Rebuilt from individual evidence

Unknown: verification boundary

The ABB ACS850-04 hardware manual lists ACS850-04-094A-5 as a frame D drive module with 94 A nominal output current, 124 A maximum output current, and 45 kW nominal output at 400 V AC.

The same manual lists 90 A light-overload current at 45 kW and 75 A heavy-duty current at 37 kW for ACS850-04-094A-5 at 400 V AC.

Inferred system position: Sits between the AC supply and the connected motor in the variable-speed drive path.

Unknown: motor data, site voltage, wiring, parameter set, firmware, physical condition, and current availability require separate confirmation.

Exact reference: ACS850-04-094A-5
Category: Drives / VFD
Evidence checked: 2026-09-12

System role

This section explains what the product does and where it acts in the surrounding system.

Function: Regulates electrical power for the connected motor as an ACS850 drive module.
System position: Sits between the AC supply and the connected motor in the variable-speed drive path.
Upstream / inputs: AC supply power and a motor-control reference feed the drive module.
Downstream / outputs: Controlled variable-frequency power passes toward the connected motor.
Limitations: Unknown: motor data, site voltage, wiring, parameter set, firmware, physical condition, and current availability require separate confirmation.

Evidence ledger

Facts, inferences, and unknowns are kept separate.

Facts

The ABB ACS850-04 hardware manual lists ACS850-04-094A-5 as a frame D drive module with 94 A nominal output current, 124 A maximum output current, and 45 kW nominal output at 400 V AC.
Confidence: high
- library.e.abb.com — retrieved 2026-09-12; high confidence
The same manual lists 90 A light-overload current at 45 kW and 75 A heavy-duty current at 37 kW for ACS850-04-094A-5 at 400 V AC.
Confidence: medium
- library.e.abb.com — retrieved 2026-09-12; high confidence

Inferences

Sits between the AC supply and the connected motor in the variable-speed drive path.
Confidence: medium
Rationale: The documented drive identity and ratings establish the product function; its placement in the supply-to-motor path is an explicit system inference.
- library.e.abb.com — retrieved 2026-09-12; high confidence

Unknowns

Unknown: motor data, site voltage, wiring, parameter set, firmware, physical condition, and current availability require separate confirmation.
Confidence: low
Missing evidence: The captured sources do not establish the installed system, complete option set, unit condition, or current commercial status.

System position diagram

ACS850-04-094A-5 receives AC power and a motor-control reference and sends controlled power to a connected motor. — The drive receives AC power and a control reference, then supplies the connected motor.

View Mermaid source

flowchart LR\n  supply["AC supply"] --> item["ACS850-04-094A-5"]\n  command["Motor-control reference"] --> item\n  item --> motor["Connected motor"]

View diagram labels

Nodes: AC supply; ACS850-04-094A-5; Connected motor
Edges: Input power; Controlled motor power

Next action

The captured evidence supports publishing ACS850-04-094A-5 as a documented abb acs850-04 drive module; verify installation-specific fit before use.

Confirm supply, motor data, wiring, options, and unit condition before installation.
