BMXAMI0800 Modicon X80 eight-channel analog input module

Schneider Electric X80 module for eight voltage or current analog input channels.

System role

Rebuilt from individual evidence

Schneider Electric identifies BMXAMI0800 as a Modicon X80 module with eight analog voltage or current inputs.

The manufacturer page places BMXAMI0800 in the X80 I/O range and documents selectable isolated or non-isolated and high- or low-level variants.

The module converts field analog measurements into input data for the Modicon controller.

Exact reference
BMXAMI0800
Category
PLC / CPU
Evidence checked
2026-09-12

System role

This section explains what the product does and where it acts in the surrounding system.

Function
The module converts eight field analog signals into controller input data.
System position
It sits between voltage or current sensors and the Modicon controller input image.
Upstream / inputs
Field sensors supply voltage or current signals to the module channels.
Downstream / outputs
The module delivers digitized analog measurements to the Modicon controller.
Limitations
Unknown: the selected channel ranges, terminal block, project configuration and condition of an individual module.
