Beckhoff C6920-1114-0050 C6 industrial PC

Evidence-backed reference for a Beckhoff C6 industrial PC used as a cabinet automation computer.

Documented system function and position

Rebuilt from individual evidence

Wake Industrial identifies C6920-1114-0050 as a Beckhoff C6 Industrial PC with two cooling fans and a 22-30 VDC supply.

The listing reports two Ethernet ports, four USB 2.0 ports, one DVI-I output, and IP20 protection.

The industrial PC is positioned in a control cabinet between automation software and connected equipment.

Unknown: Exact processor, installed cards, firmware, unit condition, and machine compatibility require separate verification.

Exact reference: C6920-1114-0050
Category: PLC / CPU
Evidence checked: 2026-09-12

System role

This section explains what the product does and where it acts in the surrounding system.

Function: Processes machine-control and visualization workloads on a Beckhoff C6 industrial PC.
System position: Sits in a control cabinet between automation software and connected field or network interfaces.
Upstream / inputs: Receives control applications and machine data through its Ethernet, USB, and field interfaces.
Downstream / outputs: Provides processed control, visualization, and network data to connected automation equipment.
Limitations: Unknown: Exact processor, installed cards, firmware, unit condition, and machine compatibility require separate verification.

Evidence ledger

Facts, inferences, and unknowns are kept separate.

Facts

Wake Industrial identifies C6920-1114-0050 as a Beckhoff C6 Industrial PC with two cooling fans, a 3.5-inch motherboard, and a 22-30 VDC supply.
Confidence: medium
- www.wakeindustrial.com — retrieved 2026-09-12; medium confidence
The listing reports two 10/100/1000BASE-T Ethernet ports, four USB 2.0 ports, one DVI-I output, and IP20 protection.
Confidence: medium
- www.wakeindustrial.com — retrieved 2026-09-12; medium confidence

Inferences

In a control cabinet, the industrial PC provides the computation and network interface between automation software and connected machine equipment.
Confidence: medium
Rationale: The system position is inferred from the exact product function and the documented system or interface context.
- www.wakeindustrial.com — retrieved 2026-09-12; medium confidence

Unknowns

Unknown: Exact processor, installed cards, firmware, unit condition, and machine compatibility require separate verification.
Confidence: low
Missing evidence: Exact processor, installed cards, firmware, unit condition, and machine compatibility require separate verification.

System position diagram

Diagram showing C6920-1114-0050 between upstream system context and downstream equipment. — System position inferred from the listed industrial-PC interfaces and cabinet-control context.

View Mermaid source

flowchart LR
  U["Upstream system"] -->|"Control and network data"| P["C6920-1114-0050"]
  P -->|"Documented downstream path"| D["Downstream equipment"]

View diagram labels

Nodes: Upstream system; C6920-1114-0050; Downstream equipment
Edges: Control and network data

Next action

The available evidence supports a claim-linked identification of C6920-1114-0050 as a Beckhoff C6 industrial PC.

Match the complete order code, processor, installed cards, firmware, and cabinet conditions before replacement.
