Omron CP1L-M30DT1-D documented industrial automation component

The controller processes CP1L machine logic and exchanges signals through its integrated digital inputs and PNP outputs. sits in the PLC control layer between field signals and connected actuators.

Documented system function

Rebuilt from individual evidence

System position and evidence limits

Omron identifies CP1L-M30DT1-D as a CP1L programmable logic controller with 30 integrated I/O and a 24 VDC supply.

The controller processes CP1L machine logic and exchanges signals through its integrated digital inputs and PNP outputs.

The listed unit provides 10 K steps of program capacity, 32 K words of data memory, one USB port, and support for up to three expansion units.

sits in the PLC control layer between field signals and connected actuators.

Unknown: the installed program, field wiring, firmware state, physical condition, and machine-specific compatibility are not established by the captured source.

Exact reference: CP1L-M30DT1-D
Category: PLC / CPU
Evidence checked: 2026-09-12

System role

This section explains what the product does and where it acts in the surrounding system.

Function: The controller processes CP1L machine logic and exchanges signals through its integrated digital inputs and PNP outputs.
System position: sits in the PLC control layer between field signals and connected actuators.
Upstream / inputs: Receives 24 VDC power and digital field signals from the controlled machine.
Downstream / outputs: Drives connected PNP outputs and exchanges configuration data through USB or supported option boards.
Limitations: Unknown: the installed program, field wiring, firmware state, physical condition, and machine-specific compatibility are not established by the captured source.
