Beckhoff CP6907-0001-0000 documented industrial automation component

The panel displays graphics from an industrial PC and carries operator input through the documented control-panel interfaces. sits between the industrial PC and the machine operator as the cabinet-mounted HMI interface.

Documented system function

Rebuilt from individual evidence

System position and evidence limits

The captured Beckhoff CP69xx ordering table lists CP6907-0001-0000 as a 5.7-inch 640 x 480 touch-screen Control Panel.

The panel displays graphics from an industrial PC and carries operator input through the documented control-panel interfaces.

The CP69xx documentation records a 24 VDC supply, DVI Extended and USB Extended links, a TFT display family, and front IP65 with rear IP20 protection for the control-panel configuration.

sits between the industrial PC and the machine operator as the cabinet-mounted HMI interface.

Unknown: the installed host PC, cable length, firmware, physical condition, and machine-specific compatibility are not established by the captured sources.

Exact reference: CP6907-0001-0000
Category: HMI / Display
Evidence checked: 2026-09-12

System role

This section explains what the product does and where it acts in the surrounding system.

Function: The panel displays graphics from an industrial PC and carries operator input through the documented control-panel interfaces.
System position: sits between the industrial PC and the machine operator as the cabinet-mounted HMI interface.
Upstream / inputs: Receives DVI graphics, USB data, operator touch input, and 24 VDC power from the connected industrial PC and supply.
Downstream / outputs: Displays the PC graphics and returns USB or touch interaction to the upstream industrial PC.
Limitations: Unknown: the installed host PC, cable length, firmware, physical condition, and machine-specific compatibility are not established by the captured sources.
