Beckhoff EL4022 - 2-channel 4-20 mA analog output terminal

Beckhoff EL4022 - 2-channel 4-20 mA analog output terminal is rebuilt from the exact-reference source and its documented system role.

System role

Rebuilt from individual evidence

Evidence boundary

The Beckhoff product page identifies EL4022 as a two-channel, 4-20 mA, 12-bit analog output EtherCAT Terminal.

Processes and transmits two electrically isolated 4-20 mA output signals. Sits between EtherCAT process data and analog field actuators.

Exact reference
EL4022
Category
PLC / CPU
Evidence checked
2026-09-12

System role

This section explains what the product does and where it acts in the surrounding system.

Function
Processes and transmits two electrically isolated 4-20 mA output signals.
System position
Sits between EtherCAT process data and analog field actuators.
Upstream / inputs
Receives output values from the EtherCAT process image.
Downstream / outputs
Transmits two isolated 4-20 mA signals to field devices.
Limitations
Unknown: Installation condition, firmware compatibility, and application sizing are not established by this source.
