Lenze EVS9323-ES 9300 standard servo inverter

Lenze EVS9323-ES is a 9300 standard servo inverter for documented open- and closed-loop variable-speed drive control.

Documented facts

Rebuilt from individual evidence

Concrete system role

Research inference

Unknown: configuration and commercial status

Fact: The Lenze manual lists EVS9323-ES as a 9300 standard servo inverter and places it in the machine control cabinet.

Fact: The controller is documented for open- and closed-loop control of variable-speed drives with PM synchronous, asynchronous standard, or asynchronous servo drive units.

Fact: The rated data lists 1.5 kW drive power, 3.9 A output current at 8 kHz, 2.9 A at 16 kHz, 320-528 V AC mains, and 460-740 V DC alternative supply.

Fact: The manual documents analog and digital setpoint interfaces, resolver and encoder inputs, and 8 kHz or 16 kHz switching operation.

Fact: The installation data lists EVS9323-ES dimensions and mounting set EJ0037 for thermally separated push-through mounting.

Fact: Lenze's C0086 table lists selection code 112 with MDSKS71-13-150 Servo-S, 1.6 kW, 150 Hz for the 9323 variants.

Inference: In a machine control chain, this controller receives power, motion setpoints, and configured feedback in the control cabinet, then regulates the variable-speed drive output.

Unknown: The installed drive and feedback pairing, option modules, firmware, application fit, lifecycle status, and current availability are not established by the captured sources.

Exact reference
EVS9323-ES
Category
Drives / VFD
Evidence checked
2026-09-11

System role

This section explains what the product does and where it acts in the surrounding system.

Function
Regulates a variable-speed drive in open- or closed-loop operation through the documented standard-servo control functions.
System position
Acts vertically in the machine control cabinet between the AC or DC-bus supply and the drive axis as part of a 9300 drive system.
Upstream / inputs
Receives three-phase AC or DC-bus power, analog or digital motion setpoints, and a configured resolver or encoder signal.
Downstream / outputs
Supplies controlled output to the variable-speed machine drive under the configured control loop.
Limitations
The controller is an industrial machine component, not a complete machine, and must be operated under the conditions in its instructions.

Evidence ledger

Facts, inferences, and unknowns are kept separate.

Facts

  • The Lenze manual lists EVS9323-ES as a type and order number in the 9300 standard-servo range.

    Confidence: high

  • Lenze classifies the ES variant as a 9300 Standard Servo servo inverter.

    Confidence: high

  • The 9300 servo controller is documented for open- and closed-loop control of variable-speed drives with PM synchronous, asynchronous standard, or asynchronous servo motors.

    Confidence: high

  • The manual places the controller as an electrical component installed vertically in a machine control cabinet or similar enclosed operating housing.

    Confidence: high

  • The EVS9323 standard-servo rated-data row documents 320-528 V AC mains, 460-740 V DC alternative supply, 1.5 kW motor power, 3.9 A output current at 8 kHz, and 2.9 A at 16 kHz.

    Confidence: high

  • The manual documents analog and digital setpoint interfaces, resolver and encoder inputs, and 8 kHz or 16 kHz switching operation for the 9300 controller.

    Confidence: high

  • The installation data lists EVS9323-ES dimensions and mounting set EJ0037 for thermally separated push-through mounting.

    Confidence: high

  • Lenze's C0086 table groups device 9323 ES/EP with selection code 112 and MDSKS71-13-150 Servo-S Y, 1.6 kW, 150 Hz.

    Confidence: high

  • The manual limits the controller to industrial machine-component use under the conditions specified in its instructions and does not define it as a complete machine.

    Confidence: high

Inferences

  • In a machine drive chain, EVS9323-ES receives supply, motion setpoints, and configured feedback in the control cabinet, then regulates the variable-speed motor output.

    Confidence: medium

    Rationale: The manual connects the controller to variable-speed motor control, cabinet installation, power ratings, setpoint interfaces, and feedback inputs; the chain description combines those documented roles.

Unknowns

  • Unknown: the installed motor and feedback pairing, option modules, firmware, application fit, lifecycle status, and current availability for this specific unit.

    Confidence: low

    Missing evidence: No current unit nameplate, configuration export, option list, firmware record, or authoritative current lifecycle and availability record was captured.

System position diagram

Block diagram of EVS9323-ES in a control cabinet: AC or DC-bus supply, analog or digital motion setpoints, and resolver or encoder feedback enter the standard servo inverter, which sends controlled output to a variable-speed drive axis.

Reading limit: system position only, not a wiring or safety drawing.

System-position inference: power, setpoints, and configured feedback enter EVS9323-ES; controlled inverter output serves the variable-speed drive axis.

Enlarged system diagram

Block diagram of EVS9323-ES in a control cabinet: AC or DC-bus supply, analog or digital motion setpoints, and resolver or encoder feedback enter the standard servo inverter, which sends controlled output to a variable-speed drive axis.

System-position inference: power, setpoints, and configured feedback enter EVS9323-ES; controlled inverter output serves the variable-speed drive axis.

View Mermaid source
flowchart LR
  supply["Three-phase AC or DC-bus supply"] --> drive["EVS9323-ES<br/>9300 standard servo inverter"]
  setpoint["Analog or digital motion setpoints"] --> drive
  feedback["Resolver or encoder feedback"] --> drive
  drive --> axis["Variable-speed drive axis"]
View diagram labels
Nodes
Three-phase AC or DC-bus supply; Analog or digital motion setpoints; Resolver or encoder feedback; EVS9323-ES 9300 standard servo inverter; Variable-speed drive axis
Edges
Power enters the inverter; Setpoints enter the control structure; Configured feedback supplies loop information; Inverter output drives the machine axis

Next action

Decision: The captured documentation supports the documented standard-servo inverter role and rated context for EVS9323-ES; this record is not a commissioning or compatibility approval.

Unknown: the installed configuration and current commercial status are not established; capture the complete nameplate and match the exact drive, feedback, option, and revision documentation before replacement or commissioning.
