TSXAEY414 Schneider Electric Modicon Premium 4-channel multirange analog input module

Receives multirange analog signals and converts them for a Modicon Premium PLC. The captured evidence defines the documented system role; installation-specific limits remain explicit.

Documented system function

Rebuilt from individual evidence

System position

Unknown: Evidence boundary

Schneider Electric identifies TSXAEY414 as a Modicon Premium four-input multirange analog input module.

Receives multirange analog signals and converts them for a Modicon Premium PLC.

The module digitizes input channels and passes their values into the Premium control system.

Sits between field analog sensors and the Modicon Premium controller input image.

Upstream: Receives analog signals from field sensors or transmitters.

Downstream: Provides digitized channel values to the Premium controller.

Unknown: The captured sources do not establish the installed wiring, firmware, unit condition, site configuration, or current availability.

Exact reference: TSXAEY414
Category: PLC / CPU
Evidence checked: 2026-09-12

System role

This section explains what the product does and where it acts in the surrounding system.

Function: Receives multirange analog signals and converts them for a Modicon Premium PLC.
System position: Sits between field analog sensors and the Modicon Premium controller input image.
Upstream / inputs: Receives analog signals from field sensors or transmitters.
Downstream / outputs: Provides digitized channel values to the Premium controller.
Limitations: Unknown: The captured sources do not establish the installed wiring, firmware, unit condition, site configuration, or current availability.
